Cervis Standard System for Overhead Cranes
Top Features:
- Series stop relays commanded by dual-contact stop switch
- Snap-in rechargeable battery, no tools required
- Contactless pushbuttons, redundant 2-step and semi-redundant 3-step
- Wireless transmitter/receiver pairing, no tools required
- Optional transmitter rubber protective boot/shoulder harness
- Robust pendant style handheld, easy to use with gloved hands
- CSA certification available
- Universal spare transmitters
Cervis Standard System
Field configurable wireless control system with over 100 of the most common crane control configurations included.
The Cervis Standard Radio System for overhead cranes is an all-in-one transmitter and receiver that covers most crane applications in use. It includes 2-speed, 3-speed, and TANDEM selections in one package. The system’s operation can also be changed as needed through its easily accessible DIP switches.
Quick Facts:
- 126 of the most common crane control configurations available
- Designed, manufactured, and supported in Pennsylvania
- 2M+ pushbutton operations
- Robust, bi-directional radio
- In stock and ready to ship
ALL RECEIVERS HAVE AC/DC OPTIONS AND ARE PRE-WIRED WITH 6' PIGTAIL
Choose Your Cervis Standard Package
Available Packages
| Item Name | Description |
|---|---|
| CERVIS 22-2-HV | CERVIS STANDARD SYSTEM, 2 MOTION 2 SPEED 110-220VAC POWER (2) HH2S-08 TRANSMITTERS (1) MU-9X9 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 22-2-LV | CERVIS STANDARD SYSTEM, 2 MOTION 2 SPEED 7-32VDC/10-28VAC POWER (2) HH2S-08 TRANSMITTERS (1) MU-9X9 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 22-2-HV-HRN | CERVIS STANDARD SYSTEM, 2 MOTION 2 SPEED 110-220VAC POWER (2) HH2S-08 TRANSMITTERS (1) MU-9X9 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 22-2-LV-HRN | CERVIS STANDARD SYSTEM, 2 MOTION 2 SPEED 7-32VDC/10-28VAC POWER (2) HH2S-08 TRANSMITTERS (1) MU-9X9 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| Item Name | Description |
|---|---|
| CERVIS 32-2-HV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 110-220VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 32-2-HV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 110-220VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 32-2-HV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 110-220VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 32-2-HV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 110-220VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 32-2-LV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 7-32VDC/10-28VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 32-2-LV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 7-32VDC/10-28VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 32-2-LV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 7-32VDC/10-28VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS 32-2-LV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED 7-32VDC/10-28VAC POWER (2) HH2S-10 TRANSMITTERS (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| Item Name | Description |
|---|---|
| CERVIS HHMS-1-HV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-1-HV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-1-HV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-1-HV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-1-LV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-1-LV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-1-LV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-1-LV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-HV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-HV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-HV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-HV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-LV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-LV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-LV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-LV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-HV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-HV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-HV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-HV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-LV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-LV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-LV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D-LV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-HV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-HV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-HV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-HV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-LV | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-LV-CN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-LV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-D2-LV-CN-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTER w/ DISPLAY (1) MU-9X15 RECEIVER, w/ CONNECTOR & HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| Item Name | Description |
|---|---|
| CERVIS HHMS-3S-1-HV | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 110-220VAC POWER (1) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-3S-1-HV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 110-220VAC POWER (1) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-3S-1-LV | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-3S-1-LV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 7-32VDC/10-28VAC POWER (1) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-3S-2-HV | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 110-220VAC POWER (2) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-3S-2-HV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 110-220VAC POWER (2) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-3S-2-LV | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER (1) ANTENNA, 900 MHz ACCESSORIES |
| CERVIS HHMS-3S-2-LV-HRN | CERVIS STANDARD SYSTEM, 3 MOTION 3 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 3 SPEED TRANSMITTER (1) MU-9X15 RECEIVER, w/ HORN INSTALLED (1) ANTENNA, 900 MHz ACCESSORIES |
| Item Name | Description |
|---|---|
| CERVIS HHMS-2-HV-TDM | CERVIS STANDARD SYSTEM, TANDEM CRANES 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTERS w/ DISPLAY (2) MU-9X15 RECEIVERS (2) ANTENNAS, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-LV-TDM | CERVIS STANDARD SYSTEM, TANDEM CRANES 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTERS w/ DISPLAY (2) MU-9X15 RECEIVERS (2) ANTENNAS, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-HV-TDM-HRN | CERVIS STANDARD SYSTEM, TANDEM CRANES 3 MOTION 2 SPEED, 110-220VAC POWER (2) HHMS 2 SPEED TRANSMITTERS w/ DISPLAY (2) MU-9X15 RECEIVERS w/ HORN INSTALLED (2) ANTENNAS, 900 MHz ACCESSORIES |
| CERVIS HHMS-2-LV-TDM-HRN | CERVIS STANDARD SYSTEM, TANDEM CRANES 3 MOTION 2 SPEED, 7-32VDC/10-28VAC POWER (2) HHMS 2 SPEED TRANSMITTERS w/ DISPLAY (2) MU-9X15 RECEIVERS w/ HORN INSTALLED (2) ANTENNAS, 900 MHz ACCESSORIES |
Configuration Possibilities
0
A/B + Trolley/Hoist Select
0
Three Speed Control
0
Interlocked & Non-Interlocked Aux
0
Four Wire Hoist Control
0
Below the Hook Controls
0
TANDEM Crane Control Set Ups
GET A FAST QUOTE
Click the button to get a free, no obligation quote of the new Cervis Standard product line for your overhead crane application.
